Sintered Bronze bar comes in many different Outside Diameters, but very limited lengths. The typical lengths are either 2", 3", or 6-1/2" Long, depending on the diameter. See the sizes available below.

SINTERED BRONZE SOLID BAR
DIA.    LENGTH    PART NUMBER
.2500"    2.000"    SPA-S841S-SBS-2-2
.3750"    3.000"    SPA-S841S-SBS-3-3
.5000"    6.500"    SPA-S841S-SBS-4-6
.6250"    6.500"    SPA-S841S-SBS-5-6
.7500"    6.500"    SPA-S841S-SBS-6-6
.8750"    6.500"    SPA-S841S-SBS-7-6
1.000"    6.500"    SPA-S841S-SBS-8-6
1.125"    6.500"    SPA-S841S-SBS-9-6
1.250"    6.500"    SPA-S841S-SBS-10-6
1.375"    6.500"    SPA-S841S-SBS-11-6
1.500"    6.500"    SPA-S841S-SBS-12-6
1.625"    6.500"    SPA-S841S-SBS-13-6
1.750"    6.500"    SPA-S841S-SBS-14-6
2.000"    6.500"    SPA-S841S-SBS-16-6
2.250"    6.500"    SPA-S841S-SBS-18-6
2.500"    6.500"    SPA-S841S-SBS-20-6
2.750"    6.500"    SPA-S841S-SBS-22-6
3.000"    6.500"    SPA-S841S-SBS-24-6
3.250"    6.500"    SPA-S841S-SBS-26-6
3.500"    6.500"    SPA-S841S-SBS-28-6
4.000"    6.500"    SPA-S841S-SBS-32-6
4.500"    6.500"    SPA-S841S-SBS-36-6
5.000"    6.500"    SPA-S841S-SBS-40-6
5.500"    6.500"    SPA-S841S-SBS-44-6
6.000"    6.500"    SPA-S841S-SBS-48-6
7.000"    6.500"    SPA-S841S-SBS-56-6
8.000"    6.500"    SPA-S841S-SBS-64-6​

SINTERED BRONZE CORED BAR
OD    IDLENGTHPART NUMBER
1    1/26-1/2    SPA-S841C-SCS-48-6
15/86-1/2    SPA-S841C-SCS-58-6
1-1/81/26-1/2SPA-S841C-SCS-49-6
1-1/85/86-1/2SPA-S841C-SCS-59-6
1-1/41/26-1/2SPA-S841C-SCS-410-6
1-1/45/86-1/2SPA-S841C-SCS-510-6
1-1/43/46-1/2SPA-S841C-SCS-610-6
1-3/85/86-1/2SPA-S841C-SCS-511-6
1-3/87/86-1/2SPA-S841C-SCS-711-6
1-1/21/26-1/2SPA-S841C-SCS-412-6
1-1/25/86-1/2SPA-S841C-SCS-512-6
1-1/23/46-1/2SPA-S841C-SCS-612-6
1-1/27/86-1/2SPA-S841C-SCS-712-6
1-1/216-1/2SPA-S841C-SCS-812-6
1-5/816-1/2SPA-S841C-SCS-813-6
1-3/45/86-1/2SPA-S841C-SCS-514-6
1-3/43/46-1/2SPA-S841C-SCS-614-6
1-3/416-1/2SPA-S841C-SCS-814-6
1-3/41-1/46-1/2SPA-S841C-SCS-1014-6
21/26-1/2SPA-S841C-SCS-416-6
25/86-1/2SPA-S841C-SCS-516-6
23/46-1/2SPA-S841C-SCS-616-6
27/86-1/2SPA-S841C-SCS-716-6
216-1/2SPA-S841C-SCS-816-6
21-1/46-1/2SPA-S841C-SCS-1016-6
21-3/86-1/2SPA-S841C-SCS-1116-6
21-1/26-1/2SPA-S841C-SCS-1216-6
2-1/81-1/86-1/2SPA-S841C-SCS-917-6
2-1/43/46-1/2SPA-S841C-SCS-618-6
2-1/47/86-1/2SPA-S841C-SCS-718-6
2-1/416-1/2SPA-S841C-SCS-818-6
2-1/41-1/46-1/2SPA-S841C-SCS-1018-6
2-1/41-1/26-1/2SPA-S841C-SCS-1218-6
2-1/41-3/46-1/2SPA-S841C-SCS-1418-6
2-1/23/46-1/2SPA-S841C-SCS-620-6
2-1/216-1/2SPA-S841C-SCS-820-6
2-1/21-1/46-1/2SPA-S841C-SCS-1020-6
2-1/21-1/26-1/2SPA-S841C-SCS-1220-6
2-1/21-3/46-1/2SPA-S841C-SCS-1420-6
2-5/81-3/46-1/2SPA-S841C-SCS-1421-6
2-3/43/46-1/2SPA-S841C-SCS-622-6
2-3/41-3/86-1/2SPA-S841C-SCS-1122-6
2-3/41-1/26-1/2SPA-S841C-SCS-1222-6
2-3/41-3/46-1/2SPA-S841C-SCS-1422-6
2-3/426-1/2SPA-S841C-SCS-1622-6
316-1/2SPA-S841C-SCS-824-6
31-1/46-1/2SPA-S841C-SCS-1024-6
31-1/26-1/2SPA-S841C-SCS-1224-6
31-3/46-1/2SPA-S841C-SCS-1424-6
326-1/2SPA-S841C-SCS-1624-6
32-1/46-1/2SPA-S841C-SCS-1824-6
32-3/86-1/2SPA-S841C-SCS-1924-6
3-1/426-1/2SPA-S841C-SCS-1626-6
3-1/42-1/46-1/2SPA-S841C-SCS-1826-6
3-1/216-1/2SPA-S841C-SCS-828-6
3-1/21-1/46-1/2SPA-S841C-SCS-1028-6
3-1/21-1/26-1/2SPA-S841C-SCS-1228-6
3-1/21-3/46-1/2SPA-S841C-SCS-1428-6
3-1/22-1/46-1/2SPA-S841C-SCS-1828-6
3-1/22-3/86-1/2SPA-S841C-SCS-1928-6
3-1/22-1/26-1/2SPA-S841C-SCS-2028-6
3-3/42-1/46-1/2SPA-S841C-SCS-1830-6
3-3/42-1/26-1/2SPA-S841C-SCS-2030-6
3-3/42-3/46-1/2SPA-S841C-SCS-2230-6
3-3/436-1/2SPA-S841C-SCS-2430-6
416-1/2SPA-S841C-SCS-832-6
41-1/46-1/2SPA-S841C-SCS-1032-6
41-1/26-1/2SPA-S841C-SCS-1232-6
426-1/2SPA-S841C-SCS-1632-6
42-1/46-1/2SPA-S841C-SCS-1832-6
42-3/86-1/2SPA-S841C-SCS-1932-6
42-1/26-1/2SPA-S841C-SCS-2032-6
436-1/2SPA-S841C-SCS-2432-6
4-1/41-3/46-1/2SPA-S841C-SCS-1434-6
4-1/42-1/26-1/2SPA-S841C-SCS-2034-6
4-1/43-1/46-1/2SPA-S841C-SCS-2634-6
4-1/21-3/46-1/2SPA-S841C-SCS-1436-6
4-1/226-1/2SPA-S841C-SCS-1636-6
4-1/22-1/46-1/2SPA-S841C-SCS-1836-6
4-1/22-3/86-1/2SPA-S841C-SCS-1936-6
4-1/22-1/26-1/2SPA-S841C-SCS-2036-6
4-1/236-1/2SPA-S841C-SCS-2436-6
4-3/43-1/26-1/2SPA-S841C-SCS-2838-6
526-1/2SPA-S841C-SCS-1640-6
52-1/26-1/2SPA-S841C-SCS-2040-6
536-1/2SPA-S841C-SCS-2440-6
53-1/26-1/2SPA-S841C-SCS-2840-6
53-3/46-1/2SPA-S841C-SCS-3040-6
5-1/226-1/2SPA-S841C-SCS-1644-6
5-1/246 1/2SPA-S841C-SCS-3244-6
636-1/2SPA-S841C-SCS-2448-6
63-1/26-1/2SPA-S841C-SCS-2848-6
646-1/2SPA-S841C-SCS-3248-6
64-1/26-1/2SPA-S841C-SCS-3648-6
746-1/2SPA-S841C-SCS-3256-6
756-1/2SPA-S841C-SCS-4056-6
846-1/2SPA-S841C-SCS-3264-6
866-1/2SPA-S841C-SCS-4864-6
966-1/2SPA-S841C-SCS-4872-6
976-1/2SPA-S841C-SCS-5672-6
Sintered Bronze Flange Bushings
Oil Less Solutions
Look for Spadone Self Lubricated Products in coming months to offer additional new products designed to help you maintain self-lubricating maintenance free operations, and a variety of bronze products from stock.
